Applications
Architectural Lighting
|
Part No. |
Led Type |
Led No./m |
CCT |
Lumen/m |
CRI |
Working Voltage |
Power |
Viewing Angle |
|
GMBT1000-350W2110 |
2110 |
350 |
2200-6500k |
1800 |
RA>90 |
DC24V |
18W |
120° |
◆ Lighting Distribution Curve and Lux-Distance Curve
◆ Connection Guide:
◆ Installation Guide:
◆ Attention:
● The strip itself and all its components could not be mechanically stressed.
● Assembly must not damage or destroy conducting paths on the circuit board. The installation must be carried out by qualified personnel;
● Please check correct electrical polarity before connection. Wrong polarity may destroy the strip
● The max. length could not be over 5 meters when serial connection. If length is over 5 meters, you could see voltage drop which can cause hazardous overload and damage the strip
● Please ensure that the transformer could bear the total load.
● Pay particular attention to the conductive slopes,avoid bending the strip so as not to slice them;
Cut the strips only along the appropriate marks;
● Strips must be installed in a suitable environment. It is the user’s responsibility to provide suitable
protection against corrosive agents such as moisture and condensation and other harmful elements
Before any application it is advisable to clean the surface where the strip will be glued;must be glued to a thermal-conductive surface, preferably aluminum
◆ Package information:
5meters per reel; 1 reel per aluminum foil bag; 100bags per carton;Total 500meters in one carton.
Carton size；46*27.5*28.5cm； N.W：11.5±5％Kg； G.W：12.5±10％Kg
